TH-M6 EVO HP Temperature Controllers up to 240 zones
GENERAL FEATURESSynchronous increase of temperatures
"Slave" function: each zone can be linked to
another with similar thermal behaviour
Plastic leakage alarm
Collective modification of all zones
Immediate and complete diagnostic
Efficient soft start (phase modulation adjustment)
Elimination of absorption peaks on three-phase
2 independent set points
Multi language
Max environmental temperature: 50°C
Main protection with circuit breaker
3-phase 400V supply or 3-phase 240V
CE Certification
TECHNICAL CHARACTERISTICS
16 A for each zone (3500 W) even simultaneously
New smaller boards (max. 6.3 A for each zone)
Ethernet connection with operator terminal
Powerful control software:
Recipes
TEST environment to automatically test the electric connections of the heaters and of the temperature probes
Process data and alarms log, graphic display and export
Synoptic ambient with drag&drop function
Log of executed operations
"Undo" function
High performing operator terminal:
Wide 15" touch screen display
Cast aluminium sturdy structure
Front USB
5 hardware function keys
Remote technical support through internet
OPTIONAL
Stand alone control panelSubtitle
